6000 Series Purge/Pressurization System
I/O Manual
Purge settings
PURGE
SETTINGS
— ENCLOSURE
VOLUME
— USER DEFINED — SETTING CORRECT
Y/N
— NUMB OF
EXCHANGES.
— 4 - 19 — SETTING CORRECT
Y/N
— PURGE FLOW — 5 — SETTING CORRECT
Y/N
— 12 — SETTING CORRECT
Y/N
— 20 — SETTING CORRECT
Y/N
— 30 — SETTING CORRECT
Y/N
— DYNAMIC — SETTING CORRECT
Y/N
— VENT FLOW
CONTROL
— ONE VENT — SETTING CORRECT
Y/N
— 2 VENTS ADD FLOWS — SETTING CORRECT
Y/N
— 2 VENTS LEAST FLOW — SETTING CORRECT
Y/N
— ENVIRONMENT — GAS, DUST, BOTH — SETTING CORRECT
Y/N
— PRESSURES — MAX OVER PRESSURE — XX.XX — SETTING CORRECT Y/N
— LOW PRESSURE — XX.XX — SETTING CORRECT Y/N
— MIN OVER PRESSURE — XX.XX — SETTING CORRECT Y/N
— TIMERS — PURGE TIMER — READ ONLY - FIXED
TIME.
— SETTING CORRECT Y/N
— SHUTDOWN TIMER — 0 - 300 SEC. — SETTING CORRECT Y/N
— UNLOCK DOOR TIMER — 0 - 300 MIN. — SETTING CORRECT Y/N
BYPASS OFF TIMER 0 - 300 SEC. SETTING CORRECT Y/N
— OPERATION
MODE
— STD, SA, FA — SETTING CORRECT
Y/N
Units
UNITS — ENGLISH OR METRIC — SETTING CORRECT Y/N
