6000 Series Purge/Pressurization System
I/O Manual
Model number designators
Control unit
Vent
6000 – DV – S2 – UN – WH – AC
AC – 100 ... 250 VAC
DC – 20 ... 30 VDC
WH – with stainless steel housing
CK – component kit
Safety Product
DV – digital solenoid/manifold included
NV – no digital solenoid/manifold included
EPV – 6000 – AA – 01
AA – anodized aluminum body and cap
SS – anodized body and 316L stainless steel cap
01 – standard configuration
02 – standard configuration, 2nd address
03 – low leakage rate for pressurization / low flow
04 – low leakage rate for pressurization, 2nd address
05 – very low leakage rate for pressurization / low flow
06 – very low leakage rate for press / low flow, 2nd address
