6000 Series Purge/Pressurization System
I/O Manual
Alarm
This provides the reason for the last system alarm.
ALARM — NONE
— NO SAFE PRESSURE
— MAX PRESSURE
— INPUT 1 BROKE/
SHORT
— INPUT 2 BROKE/
SHORT
— INPUT 3 BROKE/
SHORT
— INPUT 4 BROKE/
SHORT
— DOOR OPEN
— IMMEDIATE
SHUTDWN
— OVERLOAD
SHUTDWN
— LOST FLOW
— 13 V
— 9.5 V
— TEMP INPUT 1
— TEMP INPUT 2
— PRESSURE AS INPUT
Fault
This provides the reason for the system fault.
FAULT — NONE
— CONTROL OUTPUT 1
— CONTROL OUTPUT 2
— CONTROL VALVE
— ENCLOSURE POWER
RELAY
— INPUT 1
— INPUT 2
— INPUT 3
— INPUT 4
— 13 VOLT POWER
— 9.5 VOLT POWER
— FLOW READING
— CONFIG STORAGE
— VENT 1 UPDATE
— CRC MISMATCH
— VENT 2 UPDATE
— VALVE
— VENT 1 FLOW
UPDATE
— VENT 2 FLOW
UPDATE
— TEMPERATURE
UPDATE
— INTERNAL RAM
