55
6000 Series Purge/Pressurization System
I/O Manual
Accessories
The following accessories are available for the 6000 series purge system
Model number Description
EFC-6-SS Flush mount connector (included with unit)
CG-8 1/2" cable gland
HR-SW00 Key switch (removable in one position)
SRM-6000 Short circuit, open circuit resistor module
6000-MAN-DV-01 I.S. manifold kit with solenoid valve
EWN-1 Warning metal tag
ETW-15 Temperature warning metal tag
(1) EWN tag comes with every system ordered
6000-COUPLER-3/4-M20 3/4" NPT female to M20 female coupler for conduit, Ex de rated, nickel-plated brass
6000-COUPLER-3/4-M25 3/4" NPT female to M25 female coupler for conduit, Ex de rated, nickel-plated brass
6000-DCK-01 Explosion proof conduit seals for power EPCU and power to enclosure (1/2" NPT).
Sealing material included
6000-JCK-01 Explosion proof conduit seals for power EPCU and power to enclosure with junction
box (3/4" NPT). Sealing material included
6000-UIC-02 6000 user interface controller with bracket and cable
6000-ACC-514478 3/8" stainless steel tubing for manifold connection. 64 mm (2.5") long, 2 pcs
6000-ACC-514479 Mounting bracket with mounting screws for 6000 control unit
6000-ACC-514480 Mounting bolts for bracket to enclosure and control unit to bracket. 4 pcs.
6000-ACC-514481 3/8" lter and regulator with tting for connection to 6000 series manifold
6000-ACC-514482 Atmospheric reference kit for mounting EPV-6000-AA vent inside enclosure
6000-ACC-514483 1 - 1/2" locknut with ground and gasket for EPV-6000 vent mounted outside enclosure
6000-ACC-514484 1 - 1/2" locknut without ground and gasket for EPV-6000 vent mounted inside
enclosure
6000-ACC-514485 M12 vent cable for EPV-6000 with 4 I.S. tags
6000-TEMP-01 Temperature hub
6000-TSEN-01 Temperature sensor
6000-DPE-01-ISBC Dust-proof enclosure for 6000-TEMP and/or 6000-ISB-01
6000-ISB-01 I.S. termination board, DIN mountable
6000-CBLA-ISB-xxxx Cable harness for 6000-ISB-01 termination board
