13
6000 Series Purge/Pressurization System
I/O Manual
Mounting Instructions
Manifold assembly – left-hand or right-hand mount
3/8" ferrule tting
(included)
3/8" ferrule tting
(included)
1/4 - 20
at head screws
(4 included)
Wiring entry
Protective gas to
enclosure
Protective gas
supply inlet
3/8" SS tube
(included)
EFC-6-SS nut
(included)
EFC-6-SS
(included)
3/8" SS tube
(included)
Left-hand mount*
*Reverse ttings for
right-hand mount
