Pepperl+Fuchs 6000 SERIES User Manual

53
6000 Series Purge/Pressurization System
I/O Manual
Parts List
Control unit with housing
(1) 6000 control unit
(1) bracket for mounting control unit
(1) EFC-6-SS
(2) 3/8" stainless steel tube
(1) 3/8" male ferrule tting
(4) ¼-20 athead screws for mounting control unit to
bracket
(4) ¼-20 round head
(4) Type 4X seal washer
(4) ¼-20 bolts
(1) EWN, enclosure warning nameplate
(1) Installation/operation manual
EPV-6000 Vent
(1) EPV-6000 vent
(1) quick disconnect M12 (V1) cable
22AWG (0.33mm
2
), 5m (16.5ft.)
(1) reference tting tubing kit
(stainless steel version only)
Component kit
(1) control unit
(1) explosion-proof/ameproof enclosure
Bolts for mounting explosion-proof/ameproof
enclosure
Washers/nuts for mounting explosion-proof/
ameproof enclosure
(1) 6000-UIC-01 user interface
(1) SMK-600-CK mounting hardware for 6000-UIC-01
(1) quick disconnect M12 (V1) cable
24AWG (0.20mm
2
), 5m (16.5ft.) for 6000-UIC-01
(1) 6000-MAN-DV-01 pneumatic manifold w/solenoid
Mounting screws for 6000-MAN-DV-01
(1) EFC-6-SS ush mount connector
