6000 Series Purge/Pressurization System
I/O Manual
20 to 30 ft
3
5, 12, 20 SCFM
(0.57 to 0.85 m
3
) (141, 340, 565 l/min)
> 30 ft
3
5, 12, 20, 30 SCFM
(0.85 m
3
) (141, 340, 565, 850 l/min)
Flow rate for leakage compensation Depends on
enclosure seal
EPV-6000-xx-01, 02
0.35 SCFM @0.25” wc (10.0 l/min @ 6.3 mbar)
1.0 SCFM @0.75” wc (28.0 l/min @ 1.9 mbar)
EPV-6000-xx-03, 04
0.22 SCFM @0.25” wc (6.2 l/min @ 6.3 mbar)
0.58 SCFM @0.75” wc (16.4 l/min @ 1.9 mbar)
EPV-6000-xx-05, 06
0.15 SCFM @0.25” wc (4.2 l/min @ 6.3 mbar)
0.35 SCFM @0.75” wc (10.0 l/min @ 1.9 mbar)
Inlet tting to manifold: 3/8" tubing (included)
Outlet tting from manifold: 3/8" bulkhead tting
(included)
Mechanical specications
Storage temp:
6000 control unit (all versions) -30 °C to +80 °C (-22 °F
to +176 °F)
EPV-6000 vents: -30 °C to +80 °C (-22 °F to
+176 °F)
6000-TEMP hub: -20 °C to +70 °C (-4 °F to
+158 °F)
6000-TSEN sensor: -20 °C to +100 °C (-4°F
to +212 °F)
6000-ISB-01: -20 °C to +60 °C (-4 °F to
+140 °F)
6000-DPE-...: -20 °C to +60 °C (-4 °F to
+140 °F)
Operation temp:
6000 control unit
6000-xx-S2-UN-xx-xx -20 °C to +50 °C (-4 °F to +122
°F) For Dust application
-20 °C to +60 °C (-4 °F to +140 °F)
For Gas application
6000-xx-S2-UN-CK-xx -20 °C to +60 °C (-4 °F to +140 °F)
6000—UIC-01 -20 °C to +60 °C (-4 °F to +140 °F)
EPV-6000 vent -20 °C to +60 °C (-4 °F to +140 °F)
6000-TEMP hub: -20 °C to +60 °C (-4 °F to +140 °F)
6000-TSEN sensor: -20 °C to +100 °C (-4 °F to +212 °F)
6000-ISB-01: -20 °C to +60 °C (-4 °F to +140 °F)
6000-DPE-...: -20 °C to +60 °C (-4 °F to +140 °F)
6000 control unit
Protection class (all electronics): Type 4X, IP66
Weight: control unit: 25 lbs (11.4 kg)
Power connections: 3/4" NPT male pipe
(explosion-proof seals required)
I.S. input connections: Terminal connection inside
6000 series unit
Material:
Enclosure: 316L (UNS S31603) stainless steel
Manifold valve: Anodized 6082 aluminum
Fittings: 316L (UNS S31603) stainless steel
I.S. cable glands: M16 x 1.5 (5.5 - 10 mm) (4)
Terminal blocks EPCU:
Power terminal block: Conductors 26-14 AWG
(0.13 - 2.08 mm
2
),
torque 5-7 in-lbs (0.6 to 0.8 Nm)
I.S. terminal block: Conductors 28 - 16 AWG
(0.08 - 1.31 mm
2
),
torque 4 in-lbs (0.5 Nm)
EPV-6000 relief vent
Flow rate measurement
Flow rate is measured in increments, 5, 12, 20, 30 SCFM
& Dynamic,
(141 l/min, 340 l/min, 565 l/min, 850 l/min, & Dynamic)
Protection class: Mounting tting Type 4X, IP66
EPV-6000-___-05,06: Ingress protection from vent to
pressurized enclosure, Type 4X
Weight: 3 lb (1.4 kg)
Power connections: M12 (V1) pin connector,
intrinsically safe
(mating connector with cable comes with
vent for connection to the control unit)
LED indication GREEN – Power to EPV vent
AMBER – 2nd vent address for
two vent / one EPCU system
Max cable length: 22 AWG (0.33 mm
2
) wire = 5 m
(16.5ft)
Maximum run length 18.3 m (60 ft)
Mounting: Mounting can be any orientation to the
enclosure. Not dependent on gravity.
Mounting hole: 1 ½" NPT knockout
(Ø 2", 50.8mm) hole,
mounting with sealed nut
Material:
EPV-6000-AA-....:
Cap: Marine grade anodized 5053 aluminum
Body: Marine grade anodized 6061 aluminum
EPV-6000-SS-....:
Cap: 316L (UNS S31603) stainless steel
Body: Marine grade anodized 6061 aluminum
Spark arrestor assembly:
Protected with 304 (UNS S30400) stainless steel
spark arrestor screen. Cap is movable so that
opening can be positioned downwards.
User interface controller
Max cable length: 24 AWG (0.20 mm
2
) wire = 12.2 m (40 ft)
