2014-02
102
IC-KP-B17-AIDA1
Technical Specifications
Interface 1
Interface 2
Conformity with Standards and Directives
Ambient Conditions
Mechanical Data
Power consumption P
0
3.5 W without read/write heads
Galvanic isolation Basic insulation in accordance with DIN EN 50178, rated
insulation voltage 50 V
eff
Physical Ethernet
Protocol SMTP
HTTP
TCP/IP (port 10000)
MODBUS/TCP
EtherNet/IP
PROFINET IO
Transmission rate 10 Mbit/s or 100 Mbit/s
Physical Ethernet
Protocol SMTP
HTTP
TCP/IP (port 10000)
MODBUS/TCP
EtherNet/IP
PROFINET IO
Transmission rate 10 Mbit/s or 100 Mbit/s
Directive conformity
EMC Directive
2004/108/EC
EN 61326-1:2006
Standard c o nformity
Degree of protection IEC 60529:2001
Ambient temperature -25–70 °C (-13–158 °F)
Storage temperature -30–80 °C (-22–176 °F)
Climatic conditions Max. relative humidity 96%
Shock and impact
resistance
Oscillation (sine): 5 g, 10–1000 Hz in accordance with EN 60068-
2-6
Shock (half-sine): 30 g, 11 ms in accordance with EN 60068-2-27
Degree of protection IP67
Connection Read/write heads: Shielded, 4-pin, M12 connector
Power supply: MSTB AIDA
Protective ground: M6 grounding screw
Ethernet: RJ-45 AIDA
Enclosurematerial Aluminum, powder-coated
Mounting Snap on to 35 mm DIN mounting rail or screw mounting
Weight Approx. 1000 g
