IC-KP-B17-AIDA1
Appendix B
2014-02
121
13.1.2 Assembly object (04h)
These instances are taken from classes 64h and 65h.
Class attributes (instance 0)
Output instance attributes (instances 100d-112d)
Output instance 100d - 8 bytes
Output instance 101d - 12 bytes
Output instance 102d - 32 bytes
Output instance 103d - 60 bytes
Output instance 104d - 32 bytes
Attribute ID Name Data type Data content Access
authorization
1 Revision UINT 2 Ge t
2 Max. instance UINT 162 Ge t
100 I/O output instance USINT 100 Ge t / S e t
101 I/O output produce length UINT 8 Ge t
102
I/O input instance
1
USINT 150 Ge t
103 I/O input consume length UINT 8 Ge t
1. I/O input instance = I/O output instance + 50d
Attribute ID Name Data type Data content Access
authorization
3 Output data USINT
[0-248]
0 Ge t
Bytes Class, instance, attribute Description
0 - 7 64h, 06d, 01h Mixed mode [8]
Bytes Class, instance, attribute Description
0 - 11 64h, 06d, 02h Mixed mode [12]
Bytes Class, instance, attribute Description
0 - 31 64h, 06d, 03h Mixed mode [32]
Bytes Class, instance, attribute Description
0 - 59 64h, 06d, 04h Mixed mode [60]
Bytes Class, instance, attribute Description
0 - 7 64h, 01d, 01h Channel 1 [8]
8 - 15 64h, 02d, 01h Channel 2 [8]
16 - 23 64h, 03d, 01h Channel 3 [8]
24 - 31 64h, 04d, 01h Channel 4 [8]
