Pepperl+Fuchs IC-KP-B17-AIDA1 - Mixed Mode; Separated Mode

IC-KP-B17-AIDA1
Commands
2014-02
41
7.4.5 Mixed mode
The five identification channels (four R/W heads, one configuration channel) are addressed
using an input and an output instance, with the advantage that the controller requires less
memory.
The different parameters of the identification telegram distinguish the channels.
7.4.6 Separated mode
Each IDENT channel is addressed using a separate input and separate output instance. The
advantage here is that data processing is simplified because different IDENT channels do not
have to process the data in the same memory area.
Channel 1
Channel 2
Channel 3
Channel 4
Channel
IDENTControl
Class 64h
Instance 06 d
Attributes 1-4
1
Class 65h
Instance 06 d
Attributes 1-4
1
Input command objectOutput command object
Channel 1
Channel 2
Channel 3
Channel 4
Channel
Output command object Input command object
IDENTControl
Class 64h
Instance 03 d
Attributes 1-4
1
Class 65h
Instance 03 d
Attributes 1-4
1
Class 64h
Instance 05 d
Attributes 1-4
1
Class 65h
Instance 05 d
Attributes 1-4
1
Class 65h
Instance 01 d
Attributes 1-4
1
Class 64h
Instance 02 d
Attributes 1-4
1
Class 65h
Instance 02 d
Attributes 1-4
1
Class 64h
Instance 04 d
Attributes 1-4
1
Class 65h
Instance 04 d
Attributes 1-4
1
Class 64h
Instance 01 d
Attributes 1-4
1
