IC-KP-B17-AIDA1
Appendix B
2014-02
127
Shared services
13.1.6 Diagnostics object (instances 67h - 5)
Class attributes (instance 0)
Instance attributes (instances 1-4, channels 1-4)
Instance attributes (instance 5, IDENTControl)
Shared services
Service code integrated in service designation
Class level Instance level
0Eh Ye s Yes Get attribute single
10h Ye s Yes Get attribute single
Attribute ID Name Data type Data content Access
authorization
1 Revision UINT 1 Ge t
100 Refresh all BOOL 0 Ge t / S e t
101 Multiplex mode BOOL 0 Ge t
102 Trigger condition 3 USINT 0 Ge t
103 Trigger condition 4 USINT 0 Ge t
104 Version g ateway Bytes [52] 0 Ge t
Attribute ID Name Data type Data content Access
authorization
1 Ta g ty p e USINT 0 Ge t
2 Version Bytes [52] 0 Ge t
Attribute ID Name Data type Data content Access
authorization
1 Unused
2 Version Bytes [52] 0 Ge t
Service code integrated in service designation
Class level Instance level
0Eh Ye s Yes Get attribute single
10h Ye s No Set attribute single
