Pepperl+Fuchs IC-KP-B17-AIDA1 - Input Command Object (Instances 65 H - 6)

2014-02
126
IC-KP-B17-AIDA1
Appendix B
13.1.4 Input command object (instances 65h - 6)
Class attributes (instance 0)
Instance attributes (instances 1-6)
■ Instances 1-4: R/W heads 1-4
■ Instance 5 - Ident Control
■ Instance 6 - Mixed mode
Shared services
13.1.5 Boot-up parameter object (instances 66h - 4)
Class attributes (instance 0)
Instance attributes (instances 1-4, channels 1-4)
Attribute ID Name Data type Data content Access
authorization
1 Revision UINT 1 Ge t
100 Explicit status USINT[10] 0 Ge t
Attribute ID Name Data type Data content Access
authorization
1 Input data image
(first 8 bytes)
USINT[8] 0 Ge t
2 Input data image
(first 12 bytes)
USINT[12] 0 Ge t
3 Input data image
(first 32 bytes)
USINT[32] 0 Ge t
4 Input data image
(first 60 bytes)
USINT[60] 0 Ge t
Service code integrated in service designation
Class level Instance level
0Eh Yes Yes Get attribute single
Attribute ID Name Data type Data content Access
authorization
1 Revision UINT 1 Ge t
100 Multiplex mode BOOL 0 Get / Se t
101 Data retention time USINT 0 Get / Set
Attribute ID Name Data type Data content Access
authorization
1 Ta g ty p e USINT 3 Get / Se t
