IC-KP-B17-AIDA1
Commands
7.2 Communication via TCP/IP
7.2.1 General information on data communication via TCP/IP
The IC-KP-B17-AIDA1 device was designed to act as a TCP/IP server, which means that the
so-called client must send a command to actuate each function.
Communication is established via the TCP port 10000. Programming control software requires
accurate knowledge of TCP/IP sockets.
The following illustration shows the basic communication flow:
A connection must be established on the TCP/IP level before data can be exchanged. From this
point onwards, commands can be sent from the client to the IC-KP-B17-AIDA1 device.
Command:
Confirmation:
Byte 0 Telegram length, high byte [(N+1) div 256]
Byte 1 Telegram length, low byte [(N+1) mod 256]
Byte 2 Command code
Byte 3 Channel / Toggle bit = 0
Byte 4 Parameter
Byte 5 Parameter
Byte 6 Write data
... ...
Byte N Write data
Byte 0 Telegram length, high byte 0
Byte 1 Telegram length, low byte 6
Byte 2 Command code (echo)
Byte 3 Channel / Toggle bit (echo) = 0
Byte 4 Status FFh
Byte 5 Reply counter
Control software
Client
IC-KP-...
(Server)
Connection
on TCP/IP level
Connection
on TCP/IP level
Data exchangeData exchange
Disconnection
on TCP/IP-level
Disconnection
on TCP/IP-level
