6.3 Device settings
You must set the various parameters prior to commissioning.
The parameters are volatile and non-volatile parameters. Volatile parameters are reset to their
default setting when the system is switched off and on again.
Non-volatile parameters
Volatile parameters
Configure the read/write station with the described system commands. "99" is preset as the
data carrier type.
Warning!
Device not configured or configured incorrectly
Configure the device prior to commissioning. A device that has not been configured or
configured incorrectly may lead to faults in the plant.
Parameters Default setting Value rang e
Ge n e r a l
Multiplex mode Off On / off
R/W head
Trigger mode Off On / off
Data carrier type 99 00 ... FF
Ethernet interface
MAC address 00:0D:81:xx:xx:xx 00:0D:81:xx:xx:xx
DHCP Off On / off
IP address 169.254.10.12 yyy.yyy.yyy.yyy
Standa rd gate way 169.254.254.1 yyy.yyy.yyy.yyy
Subnet mask 255.255.0.0 yyy.yyy.yyy.yyy
Assembly inst. out 100d 100d ... 112d
PROFINET device name Empty Free text
Data hold time 50d x 10 ms 0d ... 255d x 10 ms
Parameter Default setting Value rang e
R/W head
Password mode Off on / off
Password 00000000 00000000 ... FFFFFFFF
