IC-KP-B17-AIDA1
Commands
2014-02
27
Response:
7.2.2 Command examples TCP / IP
Example 1: Preset tag type using the change tag command
Command: Change tag type on channel 1 to IPC03.
Confirmation
Response: There is a type IPH-... read/write head on channel 1.
Byte 0 Telegram length, high byte [(N+1) div 256]
Byte 1 Telegram length, low byte [(N+1) mod 256]
Byte 2 Command code (echo)
Byte 3 Channel / Toggle bit = 0
Byte 4 Status
Byte 5 Reply counter
Byte 6 Read data
... ...
Byte N Read data
Note!
The toggle bit is not required for TCP/IP.
00:06:04:02:30:33 (hexadecimal format)
00:06 Telegram length (6 bytes)
04 Command code (CT)
02 Reserved / Channel (l), toggle bit (0)
30:33 Tag t yp e ( I PC 0 3 )
00:06:04:02:FF:01
00:06 Telegram length (5 bytes)
04 Repeat command code (CT)
02 Reserved / Channel (l), toggle bit (0)
FF Status FFh (processing command)
01 Reply counter
00:06:04:02:00:02
00:06 Telegram length (6 bytes)
04 Repeat command code (CT)
02 Reserved / Channel (l), toggle bit (0)
00 Status 0 (command was executed without error)
02 Reply counter
