IC-KP-B17-AIDA1
Commands
Alternative response: There is no head on channel 1.
Example 2: Read tag using the single read command
For this command example, it is assumed that
■
the tag type IPC03 is set.
■
one type IPH-… read head is connected to channel 1.
Command: Read two words from address 0 on channel 1.
Confirmation
Response: A type IPC03 tag is located in front of the read head. The highlighted part is
the content of the tag.
Alternative response: No tag in front of the read head.
00:06:04:02:06:02
00:06 Tel e gr am le ng th ( 6 by te s)
04 Repeat command code (CT)
02 Reserved / Channel (l), toggle bit (0)
06 Status 6 (hardware error)
02 Reply counter
00:06:10:22:00:00
00:06 Tel e gr am le ng th ( 6 by te s)
10 Command code (SR)
22 Word number (2) / Channel (1), toggle bit (0)
00:00 Word address (0000)
00:06:10:22:FF:01
00:06 Tel e gr am le ng th ( 6 by te s)
10 Repeat command code (SR)
22 Word number (2) / Channel (1), toggle bit (0)
FF Status FFh (processing command)
01 Reply counter
00:0E:10:22:00:02:31:32:33:34:35:36:37:38
00:0E Telegram length (14 bytes)
10 Repeat command code (SR)
22 Word number (2) / Channel (1), toggle bit (0)
00 Status 0 (command was executed without error)
02 Reply counter
31:32:33:34:35:36:37:38 Data
00:06:10:02:05:02
00:06 Tel e gr am le ng th ( 6 by te s)
10 Repeat command code (SR)
02
Word number (0)
1)
/ Channel (1), toggle bit (0)
05 Status 5 (no tag in the detection range)
02 Reply counter
Tab le 7 . 1
1)
: No data in the telegram
