Output instance 105d - 48 bytes
Output instance 106d - 128 bytes
Output instance 107d - 240 bytes
Output instance 108d - 40 bytes
Output instance 109d - 56 bytes
Output instance 110d - 136 bytes
Bytes Class, instance, attribute Description
0 - 11 64h, 01d, 02h Channel 1 [12]
12 - 23 64h, 02d, 02h Channel 2 [12]
24 - 35 64h, 03d, 02h Channel 3 [12]
36 - 47 64h, 04d, 02h Channel 4 [12]
Bytes Class, instance, attribute Description
0 - 31 64h, 01d, 03h Channel 1 [32]
32 - 63 64h, 02d, 03h Channel 2 [32]
64 - 95 64h, 03d, 03h Channel 3 [32]
96 - 127 64h, 04d, 03h Channel 4 [32]
Bytes Class, instance, attribute Description
0 - 59 64h, 01d, 04h Channel 1 [60]
60 - 119 64h, 02d, 04h Channel 2 [60]
120 - 179 64h, 03d, 04h Channel 3 [60]
180 - 239 64h, 04d, 04h Channel 4 [60]
Bytes Class, instance, attribute Description
0 - 7 64h, 01d, 01h Channel 1 [8]
8 - 15 64h, 02d, 01h Channel 2 [8]
16 - 23 64h, 03d, 01h Channel 3 [8]
24 - 31 64h, 04d, 01h Channel 4 [8]
32 - 39 64h, 05d, 01h IDENT Control
Bytes Class, instance, attribute Description
0 - 11 64h, 01d, 02h Channel 1 [12]
12 - 23 64h, 02d, 02h Channel 2 [12]
24 - 35 64h, 03d, 02h Channel 3 [12]
36 - 47 64h, 04d, 02h Channel 4 [12]
48 - 55 64h, 05d, 01h IDENT Control
Bytes Class, instance, attribute Description
0 - 31 64h, 01d, 03h Channel 1 [32]
32 - 63 64h, 02d, 03h Channel 2 [32]
64 - 95 64h, 03d, 03h Channel 3 [32]
96 - 127 64h, 04d, 03h Channel 4 [32]
128 - 135 64h, 05d, 01h IDENT Control
