IC-KP-B17-AIDA1
Appendix A
2014-02
111
Output instance 104d - 32 bytes
Input instance 154d - 32 bytes
Additionally, the IDENTControl requires 32 bytes of input data and sends back 32 bytes of
output data as a result.
Setting tag type IPC03 on channels 1 and 2
Send a Change tagcommand as an implicit command:
Bytes Class, instance, attribute Description
0 - 7 64h, 01d, 01h Channel 1 [8]
8 - 15 64h, 02d, 01h Channel 2 [8]
16 - 23 64h, 03d, 01h Channel 3 [8]
24 - 31 64h, 04d, 01h Channel 4 [8]
Bytes Class, instance, attribute Description
0 - 7 65h, 01d, 01h Channel 1 [8]
8 - 15 65h, 02d, 01h Channel 2 [8]
16 - 23 65h, 03d, 01h Channel 3 [8]
24 - 31 65h, 04d, 01h Channel 4 [8]
Note!
The input and output instances can be configured via the display. However, setting should be
performed via the program while the plant is operating to permit easier replacement or
extension to the plant.
Ele-
ment
Implicit
telegram
Use Contents Description
1 Byte 0 Command code 04h Command CT (Change tag)
Byte 1 Channel/Toggle bit 00h The element defined the
channel.
To gg l e b i t = 0
Byte 2 Ta g t yp e ( hi gh by te ) 30h IPC 03
Byte 3 Ta g t yp e ( lo w by te ) 33h IPC 03
Byte 4 00h Not used
Byte 5 00h Not used
Byte 6 00h Not used
Byte 7 00h Not used
2 Byte 8 Command code 04h Command CT (Change tag)
Byte 9 Channel/Toggle bit 00h The element defined the
channel.
To gg l e b i t = 0
Byte 10 Ta g t yp e (hi gh by te ) 30h IPC 03
Byte 11 Ta g t yp e (lo w by te ) 33h IPC 03
byte 12 00h Not used
Byte 13 00h Not used
Byte 14 00h Not used
Byte 15 00h Not used
