Pepperl+Fuchs IC-KP-B17-AIDA1 - Page 124

2014-02
124
IC-KP-B17-AIDA1
Appendix B
Input instance 156d - 128 bytes
Input instance 157d - 240 bytes
Input instance 158d - 40 bytes
Input instance 159d - 56 bytes
Input instance 160d - 136 bytes
24 - 35 65h, 03d, 02h Channel 3 [12]
36 - 47 65h, 04d, 02h Channel 4 [12]
Bytes Class, instance, attribute Description
0 - 31 65h, 01d, 03h Channel 1 [32]
32 - 63 65h, 02d, 03h Channel 2 [32]
64 - 95 65h, 03d, 03h Channel 3 [32]
96 - 127 65h, 04d, 03h Channel 4 [32]
Bytes Class, instance, attribute Description
0 - 63 65h, 01d, 04h Channel 1 [60]
64 - 127 65h, 02d, 04h Channel 2 [60]
128 - 191 65h, 03d, 04h Channel 3 [60]
192 - 255 65h, 04d, 04h Channel 4 [60]
Bytes Class, instance, attribute Description
0 - 7 65h, 01d, 01h Channel 1 [8]
8 - 15 65h, 02d, 01h Channel 2 [8]
16 - 23 65h, 03d, 01h Channel 3 [8]
24 - 31 65h, 04d, 01h Channel 4 [8]
32 - 39 65h, 05d, 01h IDENT Control
Bytes Class, instance, attribute Description
0 - 11 65h, 01d, 02h Channel 1 [12]
12 - 23 65h, 02d, 02h Channel 2 [12]
24 - 35 65h, 03d, 02h Channel 3 [12]
36 - 47 65h, 04d, 02h Channel 4 [12]
48 - 55 65h, 05d, 01h IDENT Control
Bytes Class, instance, attribute Description
0 - 31 65h, 01d, 03h Channel 1 [32]
32 - 63 65h, 02d, 03h Channel 2 [32]
64 - 95 65h, 03d, 03h Channel 3 [32]
96 - 127 65h, 04d, 03h Channel 4 [32]
128 - 135 65h, 05d, 01h IDENT Control
Bytes Class, instance, attribute Description
