Write read only code IPC11 and IDC-..-1K
"Read-after-write" operating mode is not used.
Tags IPC11 can be programmed to behave like the IPC02 read only tag. To do this, use the
commands SX and EX. The code is read when tag type '02' or '11' is set with the commands SF
and EF.
Tags IDC-...- 1K can be programmed to behave like the ICC read only tag. This programming
occupies the first 8 bytes in the tag and occurs when the tag type '50' is set with the commands
SX or EX.
This code is read when tag type '52' is set with the commands SF or EF. If you use the
command SF or EF when tag type '50' is selected, the 4-byte read only code of the tag is
issued.
single write fixcode (SX)
Command:
Response:
The length of the read only code that is output depends on the tag type. See table "Supported
Tag Ty pe s " on p a g e 6 0 .
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 1 0 1
1
2)
Byte 2 Command code (1Fh) 0 0 0 1 1 1 1 1
Byte 3 FixLen/Channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 FixType <FixType> (high byte)
Byte 5 FixType <FixType> (low byte)
Byte 6 Data 00h ... FFh <Data>
Byte 7 Data 00h ... FFh <Data>
... Data 00h ... FFh <Data>
Byte N
3)
Data 00h ... FFh <Data>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
2)
The telegram length depends on the read only code length of the tag.
3)
N = <FixLen> + 5; Ethernet/IP: N = <FixLen> + 3
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 0
1)
Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1
1)
Telegram length, low byte 0 0 0 0 0 1 1 0
Byte 2 Command code (1Fh) 0 0 0 1 1 1 1 1
Byte 3 FixLen/Channel/Toggle bit 0 1 0 1 <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
1)
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
