K23-SSI/USB/25B-C | OPERATING SOFTWARE OS6.0
27
Value
Function
0
No average determination
(quick response to any change)
1
Flowing average determination with two cycles
2
Flowing average determination with four cycles
3
Flowing average determination with eight cycles
4
Flowing average determination with 16 cycles
5
Exponential filter, T (63 %) = 2x SAMPLING TIME
6
Exponential filter, T (63 %) = 4x SAMPLING TIME
7
Exponential filter, T (63 %) = 8x SAMPLING TIME
8
Exponential filter, T (63 %) = 16x SAMPLING TIME
9
Exponential filter, T (63 %) = 32x SAMPLING TIME
10
Exponential filter, T (63 %) = 64x SAMPLING TIME
11
Exponential filter, T (63 %) = 128x SAMPLING TIME
12
Exponential filter, T (63 %) = 256x SAMPLING TIME
13
Exponential filter, T (63 %) = 512x SAMPLING TIME
14
Exponential filter, T (63 %) = 1024x SAMPLING TIME
15
Exponential filter, T (63 %) = 2048x SAMPLING TIME
16
Exponential filter, T (63 %) = 4096x SAMPLING TIME
(very slow reaction)
CAUT
ION!
Maximum permissible frequency
When using the exponential filter, the maximum permissible frequencies at the input
must not be exceeded otherwise a data type overflow will follow!
If the frequency is still exceeded, the frequency is replaced by the m
aximum
permissible value with the corresponding setting for further calculation and an error is
output. The LED flashes
. The maximum permissible frequencies are listed below for
the corresponding settings.
FREQUENCY BASE
[0] – 1 Hz
[1] – 1/10 Hz
[2] – 1/100 Hz
[3] – 1/1000 Hz
AVERAGE
FILTER 1+2
[5] - 2x
1,073,741,823 Hz
107,374,182.3 Hz
10,737,418.23 Hz
1,073,741.823 Hz
[6] - 4x
536,870,911 Hz
53,687,091.1 Hz
5,368,709.11 Hz
536,870.911 Hz
[7] - 8x
268,435,455 Hz
26,843,545.5 Hz
2,684,354.55 Hz
268,435.455 Hz
[8] - 16x
134,217,727 Hz
13,421,772.7 Hz
1,342,177.27 Hz
134,217.727 Hz
[9] - 32x
67,108,863 Hz
6,710,886.3 Hz
671,088.63 Hz
67,108.863 Hz
