VisuNet Control Center 6
"How Tos"
After the initial connection, the device settings are automatically downloaded to the VisuNet
CC.
Figure 8.2
8.3 Uploading a Configuration to an RM / BTC
Goal
Updating device information with VisuNet CC
Pre-Condition
Connect to an RM / BTC
Update device information
1. When you have changed the device settings, upload them by clicking on the “Upload” button
on the ribbon tool bar.
2. Choose in the drop down menu if you would like to upload the data directly from a single device
or get guided through the upload Wizard and upload the settings and profiles of multiple
devices.
Figure 8.3 Upload the data of a single device
The upload window showing the upload steps is opened.
Before the settings are uploaded to the device, the local operator of the RM / BTC is
prompted to give permission for the RM / BTC to enter maintenance mode.
3. Wait until the operator accepts the request, or use the “Force Access” function in the window to
switch the RM / BTC into maintenance mode.
As soon as maintenance mode is entered, the data and settings are uploaded onto the
device.
If the upload was successful, the RM / BTC will automatically leave maintenance mode, and
the operator will be able to use the RM / BTC again.
Note
All changes done in VisuNet CC are stored in the local project file. If you want to transfer the
changes onto an RM / BTC, you need to upload them to an RM / BTC. Proceed as follows:
