VisuNet FLX System
Mechanical Installation
2023-11
51
8. Place the USB supply cable with the Velcro tape on the left side of the inner side of the adapter.
9. Connect the USB connector of the supply cable to the BPC3200-*.
Figure 4.26
Warning!
Bending radius must be maintained. The minimum allowed bending
radius is Ø80mm.
