Lumina XRMS Series III Hardware Manual Chapter 5 | X-ray Safety and Radiation Hazards 19
imaging chamber. If for some reason the emergency OFF switch has been push in to the off position,
it can be reset to ON by rotating the red knob in a counter-clockwise direction.
Figure 5.1 Key Switch
Figure 5.2 Arming Switch and Indicator
Figure 5.3 Control Panel – Living Image Software
Click to start
X-ray mode
Select X-
ray mode
