Lumina XRMS Series III Hardware Manual Chapter 8 | Fluorescence Module 57
8.2 Installation Requirements
The fluorescence equipment requires 90 - 260 VAC 50/60 Hz electrical power. The system
automatically accepts the required voltage.
8.3 Specifications
Electrical Power and Fuses
Environmental
Lamp and Fuse
Ventilation Requirements
Provide sufficient space (minimum 6 inches or 15 cm) behind the fan of the light source module so
that airflow is unobstructed. Provide a similar minimum distance behind the IVIS Lumina XRMS
Series III to enable fan cooling as well as adequate room for fiber optic cable routing.
IMPORTANT: The fluorescence equipment operates at the same voltage as the IVIS
Lumina XRMS Series III chamber and must not be used at other than its labeled voltage.
Voltage Available 90 – 260 VAC, 50/60 Hz
Power Consumption 150 W
NOTE: See Chapter 6 on page 36 for more information on additional electrical power
requirements of the IVIS Lumina XRMS Series III.
Temperature 15-25° C
Humidity 0% to 80% Non-Condensing
Type of Use Indoor (Pollution Degree 2)
Sound Level 61 dB <500 Hz
Altitude Ratin <2000 meters (6560 feet)
Lamp 150 W tungsten halogen EKE bulb with an Extended Range (ER)
coating to for increased brightness in the near infrared (NIR).
Lamp voltage: 20V
Color temperature: 2856 K°
Fuse 2.0 A, 5x20 mm, 250 VAC Slow Blow
