2.3 Dimensions
The Opera Phenix Plus system consists of Opera Phenix Plus device, Harmony PC
and monitor/keyboard cart. The setup and installation options are described in the
following chapters.
Notice
The Opera Phenix Plus is sensitive to vibrations. Blurred images can
be the consequence.
l Put the Opera Phenix Plus on a very stable bench or table.
l Do not put other devices on the same table which cause
vibrations (e.g. a centrifuge).
l Avoid any shocks or vibrations during measurements.
Component Size [cm]
(W×D×H)
Size [in] Weight [kg] Weight [lb]
Opera Phenix Plus
Plus
Instrument height
(sample lid opened)
138 × 66
85
55 × 26
34
270-300 595-662
Opera Phenix Plus
Plus with optional
pipettor
Instrument height
(housing
closed/opened)
138 × 66
95/138
55 × 26
38/55
320-350 705-772
Harmony PC 22 × 53 × 44 9 × 21 × 18 17 38
Monitor/Keyboard Cart
(keyboard tray in/out)
67 × 58/74 26 × 23/29 41 91
Opera Phenix Heavy
Duty Lab Cart
(optional)
140 × 95* × 79 56 × 38* × 31 170 375
The table will come on 4 feet, 50cm² per single foot.
plate::handlerFLEX
(optional)
214 × 95 × 181
(overall)
84 × 38 × 71 135 298
plate::handler FLEX
and incubator
(optional)
274 × 95 × 181
(overall)
108 × 38 × 71 225 496
* Rear shelf can be removed for transport, thereby depth is reduced to 80 cm (32 in).
2 Requirements
12 Opera Phenix Plus – Site Readiness
