2.4 Electrical Requirements
One individual power socket (separate circuit) is required for each system component
(see below).
Device Power Specification Power Consumption
(Max.)
Opera Phenix Plus 100 - 240 V, 50 - 60 Hz 1500 VA
Harmony PC 100 - 240 V, 50 - 60 Hz 1300 W
Monitor 100 - 240 V, 50 - 60 Hz 120W
plate::handler FLEX
(only with automation
upgrade)
100-120 V, 50 or 60Hz
or
220-240 V, 50 or 60Hz
200VA (10A fuse)
The table indicates the max. power consumption of the devices. During normal
operation the Opera Phenix Plus system (consisting of instrument, PC and monitor)
has a typical power consumption of 800 W (2730 BTU/hr).
Further requirements for plate::handler FLEX:
l Maximum rated short-circuit current: 1.5kA
l Maximum mains impedance: 2.7Ω
l Earthing system: TN-C-S
2.4.1 Cable Lengths
The power cords for instrument and PC as well as all monitor cables (Display Port,
USB and power cord) are always delivered with a length of ≥5m (197in).
