3.1.4 Automation Upgrade (plate::handler)
Notice
The plate::works PC is a dedicated computer to control the
automated plate handling (via plate::works scheduling software). It
runs with Windows
®
10 (32bit) and cannot be substituted by any
customer-supplied computer.
l The computer may not be integrated into a domain.
l Anti-virus or malware protection software may not be installed
on this computer.
3.1.4.1 Standard Configuration with PerkinElmer Switch
plate::works™
plate::works PC
NIC
192.168.99.10
Robot
PerkinElmer
HCS Instrument
Harmony PC
NIC1
192.168.1.1
NIC2
Scope of delivery
Switch
DHCP
Customer's responsibility
NAS
NIC
DHCP
Office PC
Company
Network
= 1 Gbit
= 1 Gbit
= 1 Gbit
NIC: Network Interface Card – NAS: Network Attached Storage
USB-Ethernet
Adapter
192.168.99.20
192.168.99.13
(plate::handler Flex)
or
192.168.99.11
(plate::handler II)
3.1.5 Columbus
The Columbus image storage and analysis system is installed as a client-server
system. The Columbus Server is a dedicated computer which has to be integrated into
the customer’s network. Columbus can be used via web interface on any PC within
the network.
