3.1.5.2 Standard Configuration with Columbus
Scope of instrument delivery
Harmony PC
NIC1
192.168.1.1
NIC2
Static IP
NAS
Customer's responsibility
NIC
DHCP
Office PC
= 1 Gbit = 1 Gbit
NIC
DHCP
Company
Network
Columbus
Server
¡Ý 1 Gbit
¡Ý 1 Gbit
Web Client
Server
Web Client
NIC: Network Interface Card – NAS: Network Attached Storage
PerkinElmer
HCS Instrument
3.1.5.3 Automation Upgrade with Columbus
plate::works™
plate::works PC
NIC
192.168.99.10
PerkinElmer
HCS Instrument
Harmony PC
NIC1
192.168.1.1
NIC2
Scope of delivery
Switch
Static IP
Customer's responsibility
NIC: Network Interface Card – NAS: Network Attached Storage
NAS
NIC
DHCP
Office PC
= 1 Gbit = 1 Gbit
NIC
DHCP
Company
Network
Columbus
Server
¡Ý 1 Gbit
¡Ý 1 Gbit
Server
Web Client
USB-Ethernet
Adapter
192.168.99.20
Robot
192.168.99.13
(plate::handler Flex)
or
192.168.99.11
(plate::handler II)
3 IT Policy
