four buttons. A maximum of four DSO can be connected, which has a total of eight
channels and eight buttons.
.
5.1.2. Main function keys
Below the channel selection buttons are the main function keys, as shown in the
below figure. The main function keys are used to select the main functions to be
implemented. The RUN/STOP button is to run or stop the oscilloscope. The AUTOSET
button is to automatically set the appropriate voltage and time selection.
