Installation and commissioning
27
Fig. 8 - 06
8.01.06 Mounting the table top
Table-top 906-7001-415
with cut-out
View:
Underside table top
Speedcontrolunit
Controlbox P 320
Cable duct
30x25x300
(2x)
Stand
906-3550-005/895
