Sewing
47
- The seam pattern must not have more reverse stitches than forward stitches.
- At least 2 stitches in one direction must be entered.
- Seam patterns with reverse stitches only are not permitted.
If one of the above conditions is not fulfi lled, the error message "ERROR 41"
appears on the display, and one straight stitch is sewn.
10.04 Mirror imaging shell stitches and programmed seam patterns
114-003
1
Fig. 10 - 01 Fig. 10 - 02
turning
point
mirrored seam
pattern
seam pattern
sewing direction
When the machine stops during sewing shell stitches and programmed seam patterns, the
mirror imaging function is called up by pressing key 1. In this function the seam pattern is
sewn in reverse (mirrored). If key 1 is pressed again, the mirror imaging function is switched
off again.
Depending in which direction the workpiece is turned, the position of the needle must be
altered accordingly, see Chapter 7.10.02 Function keys.
