Pfaff 1114 User Manual

Installation and commissioning
31
TE
No 0
C 700 28
By pressing the corresponding +/- key, select parameter “700“.
Turn the balance wheel in the sewing direction until the descending needle is level with
the top edge of the needle plate.
By pressing the corresponding +/- key, change the bottom value, until the top value is
set at “0“.
●
●
●
Conclude the adjustment of the sewing motor by pressing the TE/Speed key.●
8.05 Checking the function of the start inhibitor
Fig. 8 - 09
ERROR
E009
PRESS TE-SPEED
114-002
1
Switch the machine on at the main switch and tilt back the sewing head.
The error message “E 009“ must appear on the control panel.
If the message does not appear, check the setting of start inhibitor 1.
Set the sewing head in an upright position again and acknowledge the error signal by
pressing the TE/Speed key.
The machine is ready for operation again
●
●
●
