Preparation
33
6
9
.02 Winding the bobbin thread / adjusting the preliminary thread tension
Place empty bobbin 1 on bobbin winder spindle 2.
Thread the thread as shown in Fig. 9.02 and wind it around bobbin 1 a few times in a clo-
ckwise direction.
Set the preliminary thread tension by turning milled screw 3.
Press lever 4 in the direction of the arrow until it clicks into place..
Bobbin 1 is fi lled during sewing.
Setting the amount of thread wound on the bobbin:
Loosen screw 5.
Adjust stop 6 so that the bobbin winder switches off automatically when the thread is
still approx. 1 mm from the edge of the bobbin.
Tighten screw 5.
●
●
●
●
●
●
●
Fig. 9 - 02
114-015
1
2
34
5
