Setting up
9 - 2
9.02 Inserting the needle on model 474
Switch the machine off!
Danger of injury if the machine
is started accidentally!
Only use needles of system 134-35.
● Raise the roller presser 1 and swing it
out.
● Loosen screws 2 and insert the needles
so that the long groove of the left needle
is facing right, and that of the right needle
is facing left.
● Tighten screws 2 and swing roller
presser 1 back into position.
Fig. 9 - 02
The choice of needle depends on the model of the machine and the thread and
material used (see Chapter 3.02 Needles and threads).
1
2
2
