Adjustment
11 - 44
11.06.03 Knife height
Requirement
When the edge trimmer is engaged, the centre of the angular knife opening must be at the
same height as the upper edge of the needle plate.
1
Fig. 11 - 40
● Switch off the machine and engage the edge trimmer.
● Adjust milled screw 1 according to the requirement.
The basic setting may be changed depending on the material thickness.
