Adjustment
11 - 1
11 Adjustment
11.01 Notes on adjustment
All adjustments in these adjustment instructions are based on a completely installed machine
and must only be carried out by appropriately trained specialists. Covers on the machine,
which have to be removed and replaced for checks and adjustment work, are not mentioned
here.
The screws and nuts in brackets ( ) are attachments of machine parts which are to be
loosened before making the adjustment and tightened again after the adjustment has been
carried out.
The machine must be switched off for all adjustment work!
Danger of injury if the machine is started accidentally!
11.02 Tools, gauges and other accessories
● 1 set of screwdrivers with blade widths from 2 to 10 mm
● 1 set of open-ended wrenches with opening sizes from 7 to 13 mm
● 1 set of allen keys from 1.5 to 6 mm
● 1 clamp (Order No. 08-880 137-00)
● 1 metal rule (Order No. 08-880 218-00)
● 1 gauge (Order No. 08-880 136-01)
● Sewing thread and test material
11.03 Abbreviations
TDC = top dead center
BDC = bottom dead center
