Adjustment
11 - 7
● Making sure that there is some play in the bevel gear, tighten screws 1.
● With retaining collar 7 touching bevel gear 8 tighten screws 2 and 3.
● Adjust needle guard 6 according to Requirement 3.
10
When the hook is replaced, care
must be taken to see that markings 9
and 10 are on the same side.
9
