Adjustment
11
1
.06.06
F
eeding motion of drop f
eed
Requirement
At the longest stitc
h length set
ting and with the needle bar in position
0.6 past t.d.c.
(blo-
c
king hole 1) the f
eed dog must not mov
e when the reverse-f
eed control is operated.
●
T
urn f
eed eccentric
1
(screws
2
) according to
Requirement
. Mak
e sure that the cutout
in the f
eed eccentric is visible.
Fig. 1 - 07
