Adjustment
18
●
While continuously operating the f
eed reverse k
ey
, adjust eccentric
1
(screws
2
) so that
the slot is pointing tow
ards the operator and lever
3
does not mo
ve.
1
.06.1
2
F
eeding motion of the top feed dog
Requirement
When the needle bar is positioned
0.6 mm past t.d.c
(adjustment hole 1) and the maximum
stitc
h length is set, lev
er
3
should not mov
e when the feed re
verse ke
y is operated.
Fig. 1 - 14
1
2
3
17
19
