Pfaff 487 Adjustment Manual

Adjustment
8
● Set feed regulator lever 1 in its lowest position.
● Turn bush 2 (screw 3) so that mark 4 is facing downwards and the edge of the milled
surface is at an angle of approx. 45° to the front side of the machine.
● (For the fi nal adjustment, see Chapter 1.0.06.16 "Top feed synchronization".)
● Insert a suitable pin or allen key in hole 5 of tensioning ring 6 and hold shaft 7 with it
fi rmly.
● Turn shaft 7 (screw 8) according to Requirement.
Fig. 1 - 04
56
8
7
45
°
2
3
4
1
1
.06.03 Neutral position of drop feed ( Adjustment with the gearcase closed
Requirement
At stitch length setting "O" the drop feed must not make any feeding movement when the
balance wheel is turned.
