Adjustment
6
1.06 Adjusting the basic machine
1
.06.01 Balancing weight
Requirement
With the needle bar at b.d.c. the underside of the needle bar must be at a distance of
approx. 16.5 mm from the needle plate.
Re-position needle bar 1 (screws 2) according to Requirement.
Fig. 1 - 02
1
2
16,5 mm
