Pfaff 487 Adjustment Manual

Adjustment
38
1.07 Parameter settings (only on machines with EcoDrive and control unit P40 ED)
Parameter settings are described in the separate operations manual for
the drive, and may only be changed by qualifi ed technicians!
1.07.01 Parameter list
Group Parameter Description User lever Setting range Set value
1
105 Speed for start backtackl B, C 300 - 2000 1200
110 Speed for end backtack B, C 300 - 2000 1200
6
606 Speed min. B, C 30 - 300 180
607 Speed max. B, C 300 - 6000
▲
609 Cutting speed B, C 60 - 300 180
660 Bobbin thread control
0 = off, 1 = thread monitor,
2 = reverse counter
A, B,
C
0 - 2 0
7
700 Needle position 0
Needle reference position
B, C 0 -255 *
702 Needle position 1 (needle lowered) B, C 0 - 255 90
703 Needle position 2 (take-up lever raised B, C 0 - 255 236
705 End cutting signal B, C 0 - 255 200
706 Start cutting signal B, C 0 - 255 136
707 Needle position 9 (start thread tension
release/start thread catcher)
B, C 0 - 255 164
760 Multiplier for the fi xed value (200)
stitch count
A,B,
C
0 - 250 5
799 Selected machine class C 1 - 3 1
8
800 Rotating direction of the motor C 0 - 1 1
V
See Chapter 3 Specifi cations (in the machine instruction manual).
*
Adjustment see Chapter 8.05 Basic position of the machine drive unit (in the machine instruction
manual).
Further parameters and the description for an internet update of the machine
software and reset /cold start of the machine can be found in the instruction
manual for the drive
