Adjustment
22
●
Press the re
verse-f
eed lever and loosen nut
1
accessible behind it.
●
P
osition screw
2
in the slot according to
R
equirement
and tighten nut
1
.
Fig. 1 - 18
1
2
1
.06.1
6
S
ync
hronizing the top f
eed
Requirement
When the f
eed regulator levers f
or stitc
h length and top-f
eed stroke are set at "3", both
top f
eed and bot
tom f
eed must move at the same strok
e when the balance wheel is turned.
21
23
