Adjustment
26
●
T
urn bobbin case opener bearing
1
(screws
2
) according to
R
equirement
.
Fig. 1 - 22
2
1
4
3
0,5 mm
1
.06.20
Bobbin case opener height
Requirement
When bobbin case opener
3
is at its lef
t rev
ersal point the top side of its fi
nger must be
0.5 mm
abov
e the lower edge of bobbin case trip
4
.
25
27
