Adjustment
23
●
T
urn bush
1
(screw
2
) according to
R
equirement
. Make sure that the eccentricity of
bush
1
faces do
wnwards.
Fig. 1 - 19
1
2
1
.06.1
7
Stitc
h length alignment
Requirement
When the stitc
h length is set at "3" the f
eed stroke must be the same in f
or
wards and re-
verse f
eeding
22
24
