2:9
A
B
Preparations
Winding from the second spool pin
Insert the second spool pin in the hole provided.
Place the thread on the second spool pin.
Threading
Place the thread into guide A from the front and pull it counter clock-
wise around the pre-tension device B. Make sure the thread is pulled
securely inside the pre-tension device for correct thread tension. Pull
the thread under the thread guide C (from back to front). Wind the
thread tail around the bobbin several times in a clockwise direction.
Winding
Turn on the machine. Hold the end of the thread fi rmly and press the
foot control. As soon as the bobbin is full, the winding action will stop
automatically. Push the bobbin to the left, cut the thread and remove
the bobbin from the winder.
Note: If you want to wind a bobbin before you start to embroider, you need
to prepare the machine for embroidering, in the steps 1-6 as described on
page 3:14, to be able to wind your bobbin.
