Presser foot lift
The machine moves to the corresponding positions when the appropriate buttons are pressed:
• Raised position [8 mm above needle plate]
The limit switch must be reached.
• Middle position [5.3 mm above needle plate]
• Lowered position [Foot resting on needle plate]
• Release lifter [10,3 mm above needle plate]
The manual lifter must be released
• Knee lift [Presser foot follows the knee lift]
The positions can be selected manually.
After pressing the knee lift button, the presser foot must follow the movement of the knee lift (visual check).
Please press now the relevant buttons:
either button „+“ = OK (test was successful)
or button „-“ = ERROR (test was not successful)
plus button „i“ = End (end of test with possibility to go to the next test)
The current test can be interrupted with the „i“ button.
If the „Full test“ mode is activated, the next test will be automatically executed after acknowledgement of
the visual check.
59. Buttonhole control
The buttonhole gauge consists of a measuring rail and a dual-track forked light barrier.
The 90° out-of-phase signals generated when the measuring rail is moved are counted by the hardware, with
the total running up or down depending on the direction of movement.
The operator is requested to insert the measuring rail to the limit.
The measuring rail must be pulled out by pressing the „START“ button.
The counter reading is displayed in the form of a number.
If a value of min. 110 is not reached, an error message will be issued.
An evaluation window (OK or Error) is displayed after completion of the test.
Press the button „i“ = End (end of test with possibility to go to the next test)
The current test can be interrupted with the „i“ button.
If the „Full test“ mode is activated, the next test will be automatically executed after completion of the test.
