109
63. Overload protection
After pressing the foot control a further time, the overload protection is tested:
The operator is requested to block the handwheel manually for about 10 seconds; this causes the machine
motor to shut down for about 4 seconds.
Important:
The operator is only requested to release the foot control after these 4 seconds.
Test end.
All tests
If the function „All tests“ is activated, all above mentioned tests are executed in the indicated order and the
results are recorded.
The test results are shown on the screen after pressing the „Continue“ push-button.
If the test was ok, „OK“ appears. If the test was skipped in the individual dialogue, this is indicated by „-“.
Otherwise „ERROR“ appears.
Full test
Display: OK Keys: OK
Touch panel: OK Signal generator: OK
Foot control: OK Sewing unit: OK
Presser foot lift: OK Buttonhole control: OK
Synchronizer: OK Machine motor: OK
Overload protection: OK Bobbin thread monitor: OK
End = „i“ key
Touch the „Main menu“ button to return to the sewing program.
