65
• Fold the baseplate towards the machine.
• Attach the cable clip.
• Fasten the baseplate on the housing with the three fastening screws.
• Attach the face plate.
• Attach connection plugs 2 and 3 onto the circuit board of the front housing shell.
• Install the sewing lamp cable.
• Mount the facing panel of the front housing panel.
• Insert the housing insert and fasten with the torx screws.
• Attach the top cover.
The following points must be checked and adjusted:
• Section 19 „Adjustment of bobbin thread tension“
• Section 20 „Adjustment of needle thread tension“
• Section 22 „Adjustment of equal forward and reverse stitch length“
